NeuraLabel Sprint – Compact High-Speed Label Printer

Neuralabel

Sprint System

The NeuraLabel Sprint is the latest short-run label printing solution, delivering full-color, high-resolution prints with exceptional speed and efficiency. Designed for on-demand desktop printing, it features a small footprint, user-friendly interface, and integrated gap sensors, eliminating the need for preprinted registration marks and reducing media costs.

CALL FOR PRICING

Print Short to Medium Label Runs

Full-color or black-and-white high quality labels
Ideal for printing a single label at a time or large label batches
Great for labels as small as a postage stamp (1"x1") or as large as a drum (legal size and larger)
Chemical resistant ink suitable for cleaning and sanitizing products
Built-in sensors detect label edges for perfect placement of every label
Durable, lightweight aluminum case built to last
American designed, engineered and manufactured
Optional roll handling equipment available

Overview+

NeuraLabel Sprint: Compact, High-Speed Label Printing

Built with durable, lightweight aluminum, the Sprint ensures long-lasting performance and includes an optional media roll unwinder for extended print runs. Whether for small batches or quick-turnaround jobs, the Sprint provides a cost-effective, high-quality label printing solution.

Print Speed | Up to 6 ips (inches per second)
Ink Type | Pigment or Dye Option
Media Width | 1″ – 8.5″ wide
Roll Diameter | Up to 8″ diameter
Updates | Remote Updates
Power Supply | Built-in Universal, 110V or 220V
Warranty | 1 Year On-Site Warranty Included

Specifications +

Weight | 80 lbs
Dimensions | 34 × 19 × 17 in
PRINT METHOD | MEMJET WATERFALL PRINTHEAD TECHNOLOGY 11 INTERGRATED CIRCUIT (IC) CHIPS – 70,400 NOZZLES (6,400 PER IC CHIP)
INK TYPE | Pigment
PRINT RESOLUTION | Up to 2400 dpi
PRINT SPEED | Up to "20" per second
PRINT WIDTH | 8.5 INCHES (216MM)
MEDIA TYPES | COMPATIBLE WITH A WIDE RANGE OF PAPER, POLYESTER, POLYPROPYLENE, AND VINYL LABEL STOCKS
MEDIA WIDTH | 1.5" – 8.65" (38.1mm – 219.7mm)
MEDIA THICKNESS | MINIMUM 0.005" (0.13MM) MAXIMUM 0.01" (0.3MM, INCLUDING LINEAR)
MEDIA CORE DIAMETER | REQUIRES 3" (76.2MM) CARDBOARD CORE
MEDIA SENSORS | GAP, CONTINUOUS, BLACK MARK
MEDIA DIE-CUT LABEL GAP | MINIMUM 0.125" (3.0MM) – MAXIMUM 0.3" (8.0MM)
MEDIA BLACK MARK SIZE | (3MM WIDE, 25.4MM LONG ON LEFT)
MAX DIE-CUT LABEL LENGTH | 12" (304.8MM)
INTERFACES | USB, TCP/IP (MANUAL IP CONFIGURATOIN OR DHCP), GPIO AVAILABLE FOR EXTERNAL DEVICE CONTROL
OPERATING SYSTEM | WINDOWS 7, 8, 10 (32 AND 64 BIT)
BARCODE FONT | 1D BARCODE AT LEAST GRADE B (CODE39) WITH 10MILS BAR WIDTH
2-DIMENSIONAL CODE PRINTING | 2D BARCODE AT LEAST GRADE B (PDF417) WITH 10 MILS CELL SIZE
OPERATING TEMPERATURE | 15 – 35 C (59 – 95 F) AT RH 20 – 80%
STORAGE TEMPERATURE | -5 – 50 C (23 – 113 F) AT RH UP TO 85%, NON-CONDENSING AT 65 DEGREES
OVERALL DIMENSIONS | 18.9" (480MM) W, 19" (485MM) D, 21.1" (535MM) H
WEIGHT | 83 LBS. (37.6KG)
RATED VOLTAGE | AC 110V – 220V
RATED FREQUENCY | 50 -60HZ
WARRANTY | 1 YEAR
